Economical 250 Series Lead-Free Wave Soldering (Computer / Touch / Button)
Category:Wave soldering series
Profile:Features:• The heating system adopts long-life electric heating tube and casing embedded structure, which is easy to maintain and replace. Use new insulation materials.
• The heating system uses high precision, integrated imported brand temperature control closed loop PID adjustment. Accurate temperature control and high reliability.
• The transportation speed is controlled by liquid crystal digital display governor, which is steplessly adjustable and convenient to control.
• Very economical low pressure atomization coating. Fully automatic detection of PCB scanning spray.
• Hydraulic integral flap structure. Large format observation window with simple appearance and easy maintenance.
• Titanium claws made of titanium titanium alloy. Rugged, non-deformable, consistent, and keep the PCB soldered smoothly.
• The stirring motor adopts a brand-name wave motor combined with a brand-name inverter to achieve smooth stepless speed regulation to ensure the smoothness of the peak surface.
• High efficiency far infrared preheater with high thermal efficiency.
• Nozzles, motors, frequency converters, temperature controllers, sensors, solenoid valves, photoelectric eyes, relays, etc. are all brand-name products.
